24 Volt 2 Port Type Solenoid Valve , Pneumatic Diaphragm Pilot Valve

24 Volt 2 Port Type Solenoid Valve , Pneumatic Diaphragm Pilot Valve

    • 24 Volt 2 Port  Type Solenoid Valve , Pneumatic Diaphragm Pilot Valve
  • 24 Volt 2 Port  Type Solenoid Valve , Pneumatic Diaphragm Pilot Valve

    Detail produk:

    Place of Origin: Ningbo China(Mainland)
    Nama merek: FLUIDAC or OEM
    Sertifikasi: ISO9001
    Model Number: B223-08-AC220V

    Syarat-syarat pembayaran & pengiriman:

    Minimum Order Quantity: 5 piece
    Harga: USD10--
    Packaging Details: Boxes, Cartons,Wooden cases,Pallets
    Delivery Time: Within 20 days after receiving payment or deposit
    Payment Terms: TT Advance/30% deposit,70% by copy Bill oflading,Western Union,MoneyGram,Paypal
    Supply Ability: 10000 Pieces Per month
    Kontak
    Detil Deskripsi produk
    Orifice size: 10mm,13mm,20mm,25mm,40mm,50mm Series: B223 Series
    Port size: G18”~G2” e. Body Material: Brass
    Product Name: Solenoid Valve Type: Two Position Two Way
    Voltage: DC12V, AC220V, AC380V, DC24V
    Cahaya Tinggi:

    2 Way Solenoid Valve

    ,

    Water Solenoid Valve





    24 Volt 2 Port Type Solenoid Valve , Pneumatic Diaphragm Pilot Valve

    Orifice size 10mm,13mm,20mm,25mm,40mm,50mm type solenoid valve B223 series Diaphragm pilot port size G18”~G2” e.





    Quick Detail:



    * B223 Series Solenoid valve aperture flow 10mm, 13mm,20mm,25mm,40mm,50mm interchangeable

    * Two position two way diaphragm pilot

    * Body material brass

    * Port Size G1/8”,G1/4”,G3/8”,G1/2”,G3/4”,G1”,G1-1/4”,G1-1/2”, G2”

    * Seal NBR,EPDM or VITON for option

    * Fast respond,low noise,low consumption

    * Stable design,long serive life





    Applications:





    B223 series two position two way solenoid valve acting as on and off switch function automatically for its working system by the involving of power electricity magnetic.

    B223 series widely use in the Pneumatic,water and oil circuit system to connect through or turn off the serving system.



    Specifications:



    ORDERING CODE

    B223

    08

    V

    AC220V

    Type

    Port size

    Seal Material

    Voltage

    B223:B223 type Diaphgragm solenoid valve

    06:G1/8"

    V:VITON

    DC12V

    08:G1/4"

    10:G3/8"

    AC24V

    15:G1/2"

    E:EPDM

    DC24V

    20:G3/4"

    25:G1"

    AC220V

    35:G1-1/4"

    Blank:NBR

    40"G1-1/2"

    AC110V





    SPECIFICATION

    Model

    Orifice

    Size

    Port

    Connection

    Pressure

    Ambient

    Temperature

    Medium

    Temperature

    Kv Value

    Power

    Consumption

    Frequency

    (mm)

    (G)

    (MPa)

    (℃)

    (℃)

    (m3/h)

    AC(VA)

    DC(W)

    (Hz)

    BV22308

    10

    G1/4″

    0.03~1.0

       -10~+55

    -10~+90

    2

    14

    8

    ≥1

    BV22310

    G3/8″

    BV22315

    13

    G1/2″

    3.6

    BV22320

    20

    G3/4″

    8.3

    ≥0.5

    BV22325

    25

    G1″

    11

    BV22332

    40

    G1-1/4"

    0.07~1.6

    25

    ≥0.33



    24 Volt 2 Port  Type Solenoid Valve , Pneumatic Diaphragm Pilot Valve 0

    Model

    G

    C

    F

    L

    BV22308

    G1/4″

    38

    14

    50

    BV22310

    G3/8″

    38

    14

    50

    BV22315

    G1/2″

    45

    16

    52

    BV22320

    G3/4″

    45

    16

    63

    BV22325

    G1″

    65

    18

    82

    BV22332

    G1-1/4"1

    96

    20

    132

    BV22340

    G1-11/2″

    96

    20

    132

    BV22350

    G2″

    111

    22

    160



    Model

    J

    A

    B

    H

    K

    BV22308

    26

    71

    85

    40

    71

    BV22310

    26

    71

    85

    BV22315

    27

    82

    96

    80

    BV22320

    31

    82

    96

    BV22325

    41

    96

    117

    90

    BV22332

    58

    112

    145

    132

    BV22340

    58

    112

    145

    BV22350

    70

    125

    166

    160
